Garage Door Opener Repair Concerns and Installation - 5 min

Video Script:

As recently as 10 to 15 years ago a residential garage door opener was considered to be a luxury, today most home owners consider them to be an essential garage door item. Garage door openers are virtually everywhere. For this reason it is necessary for the professional garage door installer to understand the steps to proper opener installation. Over then next few minutes we'll take a look at the residential garage door opener, it's safety features and correct installation procedures. Let's get started.

Understanding UL 325 and preparing the job site - Underwriter laboratories is a non-profit organization that specializes in the development of standards for many different products. The standard that applies to door opening systems is Ul 325. In its earliest stages openers were tested by UL as electric motors but in 1973 UL recognized that openers were more than just motors and required that if a motor contacted an obstruction within 2" of the floor, that it automatically reverse within two seconds. In 1982 a second reversal feature was added to UL 325 stating that the opener must automatically reverse the door to its open position, if the close limit was not reached within 30 seconds. In 1993 UL 325 was again revised to include another feature: external entrapment protection devices, such as photo detectors and safety edges, are required.

Whether or not you installed the door there are some things to consider when evaluating the site conditions. First in order for the safety features to work correctly and the life of the opener to be maximized the door opening must be properly constructed and the door opener must be properly installed. Understand what type of door you will be attaching an opener to, the opener installation will be different for different door types.

Openers - there are 4 types of openers they are: Chain type, screw type, belt type and direct drive. The chain, screw and belt types are all installed in similar fashion and will be covered in this training video. The direct drive type requires specific manufacturers instructions. Determine if there are any gaps between the floor and the door, gaps across the top of the floor might cause the automatic reversal feature to operate incorrectly. Make sure there is an electrical outlet close to the opener, if there isn't one remember that electrical codes may require that a licensed electrician perform any wiring required. Some electrical code may even require wiring the power source through conduit. Most important, never use an extension cord as a method of providing power.

Installing the opener - Before we begin its important to mention that installation procedures vary from garage to garage, low ceiling or finished or not finished ceilings all come into play when installing an opener, with that in mind today we'll address common ceiling heights for finished or un-finished garage ceilings. With the door at it's high-rise point, the point where the top edge of the door is highest above the floor, measure the distance from the top of the door to the ceiling, then close the door and at the centre of the header make a mark 2" above the high-rise point you just measured. Now mark the bracket, pilot drill the holes and attach the bracket to the header.

Once again open the door, place a 1x4 board on top of the door section, centre the opener and rest it atop the 1x4 this gives you the correct clearance for operating the door. At this time you'll also want to connect the opener rail to the header bracket, too do this you'll need to reach between the bottom of the door and garage header. Fasten angle-iron to the two closest joists above the opener, then cut and fasten angle brackets from the ceiling angle-iron to the opener, always use locking nuts or washers as provided by the manufacturer. Now, close the door and attach the opener arm assembly. Be sure to position the trolley so that it's about 2" back from vertical.

Next attach the emergency release cord, the cord should hang about 6' above the garage floor. Now manually open and close the door to ensure smooth operation. Next assemble and mount the IR safety system so that the sensors are between 4" and 6" above the floor, checking with the manufacturers instructions for exact mounting procedures. Run the low voltage wires back to the motor assembly in a neat fashion, make sure to use insulated staples, metal staples can short the wires and the opener will not operate properly. At this time you can also connect the wall control station. Make sure the wall station is mounted 5' from the floor so that children can not play with it. Also, ensure the control is mounted within line of site with the floor and finally plug in the opener to the ceiling plug.

Opener Adjustments - Now that the opener is installed we can adjust the settings and up and down travel limits, obviously different manufacturers have different adjustment methods so be sure to refer to the manufacturers instructions for specifics. With that said here are some basic guidelines: Set the up and down force to minimum activate the opener to open and close the garage door stops during the up and down travel the up or down sensitivity setting will need to be adjusted according to the manufacturers instructions. The opener is adjusted correctly when the garage door can travel to the fully open or fully closed position without encountering any difficulties. Now let’s look at travel limits. The limit adjustments control how far the garage door will open or close.

Up travel should be set so that the bottom edge of the door is no lower than the bottom edge of the garage door header and no higher than 2" above the bottom edge of the header. Down travel should be set so that the door closes gently in the closed position. If the door stops and reverses upon hitting the floor or stops before hitting the floor the down travel limiter will need to be adjusted as per the manufacturers instructions. Our next step is to check for proper operations of the safety reversal features, we'll begin with door force. The door force mechanism must be in proper adjustment at all times.

This ensures that the garage door will reverse its motion if it encounters any obstruction on its downward travel and stop its motion if an obstruction is encountered on its upward travel. With the door open lay a 2x4 or similar obstacle flat in the centre of the garage door opening, when the door hits the obstacle it should reverse and go in the opposite direction. If the door does not reverse after hitting the obstacle then the downward travel must be adjusted.

Now, let’s verify the IR reversal function. Place an obstacle in the path of the IR beam, if the opener will not activate at this time, the IR system is working correctly. Openers have one other IR safety feature, if the IR system is not functioning the homeowner can close the door by pressing and holding the closing button on the wall station, but here's the catch... if the door does not reach its' fully closed position while the button is pushed the door will automatically open as soon as the button is released. Keep in mind this constant pressure override system can not be triggered from the remote openers, only from the wall station.

Finishing the Installation - Okay, here are a few final simple tasks you'll need to do to finalize your installation. Install the opener lightbulbs, making sure the bulbs have a wattage equal to or lesser than recommended by the manufacturer. Apply the warning labels, each opener is provided with one or more labels to warn or instruct homeowners in the safe operation and regular testing of the opener. These must be installed according to the manufacturers instructions. You must be sure to affix a label by the wall mount button, this is a required label and is not subjective to the customers preference. If a customer asks you not to apply the label by the wall button explain that it is a safety requirement and you must put it there.

Next help the customer program the remote controls, each manufacturer has different programming sequences so refer to the manufacturers manual for specific instructions or details. Finally be sure to review the main operation and safety features of the door opening system with the homeowner, including the manual release, wall control, IR System and safety labels, discuss the warranty and leave the homeowner the installation manual. You've now completed the installation of your customers new garage door and opener, but remember the example we've shown you is a typical installation and not all of your assignments will follow this process so the most valuable tool in your ongoing training is the manufacturers instructions.
